Power Source |
R6P (AA) × 6 (9 V DC) or R6P (AA) × 4 (6 V DC) |
Rated Output |
6 W (when using six R6P batteries) |
Maximum Output |
10 W (when using six R6P batteries) |
Battery Life |
When using six R6P batteries (JEITA)(*1)
Voice: Approx. 8 hours, Siren: Approx. 20 minutes
When using four R6P batteries(*2) (JEITA)(*1)
Voice: Approx. 5 hours, Siren: Approx. 10 minutes |
Audible Range |
Voice: Approx. 250 m (JEITA)(*1), Siren: Approx. 315 m (JEITA)(*1) |
Signal Sound |
Siren (sounds at 5 seconds intervals) |
Frequency Response |
450 - 6,000 Hz (SPL -20 dB) |
Magnetic Circuit |
Neodymium magnet, inner magnet type |
Diaphragm |
Polyimide film (voice coil, bobbin) |
Anti-bacteria Treatment |
Mouth and handle |
Water Protection |
IPX5 |
Operating Temperature |
-10℃ to +40℃ |
Finish |
Horn: ASA resin, clear red
Other: ASA resin, red
Strap: Nylon, black |
Dimensions |
154 (W) × 266 (H) × 250 (D) mm |
Weight |
680 g (without batteries) |
Accessory |
Battery spacer …1 |
Option |
Wall mounting bracket for megaphone: SP-1100 |
| |
|
| |
|
|
|
